Cisco MDS 9000 Series Command Reference

Send documentation comments to mdsfeedback-doc@cisco.com
2-22
Cisco MDS 9000 Family Command Reference
OL-8413-07, Cisco MDS SAN-OS Release 3.x
Chapter 2 A Commands
autonomous-fabric-id (IVR topology database configuration)
• The autonomous fabric ID (AFID), which distinguishes two VSANs that are logically and physically
separate, but have the same VSAN number. Cisco MDS SAN-OS Release 1.3(1) and later supports
only one default AFID (AFID 1) and thus does not support non-unique VSAN IDs in the network.
As of Cisco MDS SAN-OS Release 2.1(1a), you can specify up to 64 AFIDs.
Note Two VSANs with the same VSAN number but different fabric IDs are counted as two VSANs out o f the
128 total VSANs allowed in the fabric.
The following command enters the configuration mode, enables the IVR feature, enters the VSAN
topology database, and configures the pWWN-VSAN association for VSANs 2 and 2000.
switch# config terminal
Enter configuration commands, one per line. End with CNTL/Z.
switch(config)# ivr enable
switch(config)# ivr vsan-topology database
switch(config-ivr-topology-db)# autonomous-fabric-id 1 switch 20:00:00:00:30:00:3c:5e
vsan-ranges 2,2000
Related Commands Command Description
ivr enable Enables the Inter-VSAN Routing (IVR) feature.
ivr vsan-topology database Configures a VSAN topology database.
show autonomous-fabric-id database Displays the contents of the AFID database.
show ivr Displays IVR feature information.

Cisco MDS 9000 Series Specifications

General

Category	Switch
Operating System	Cisco NX-OS
Ports	Varies by model
Protocols	Fibre Channel (FC), Fibre Channel over IP (FCIP), iSCSI
Redundancy	Redundant supervisors, power supplies, and fans
Management	Cisco Data Center Network Manager (DCNM), CLI, SNMP
Virtualization Support	VSANs (Virtual SANs)
Security Features	Fibre Channel Security Protocol (FC-SP)
Hot Swappable Components	power supplies, fans
Power Supply Options	AC and DC options available
