Cisco MDS 9000 Series Command Reference

Send documentation comments to mdsfeedback-doc@cisco.com
22-348
Cisco MDS 9000 Family Command Reference
OL-8413-07, Cisco MDS SAN-OS Release 3.x
Chapter 22 Show Commands
show topology
show topology
To display topology information for connected switches, use the show topology command.
show topology [vsan vsan-id]
Syntax Description
Defaults None.
Command Modes EXEC mode.
Command History
Usage Guidelines None.
Examples The following example displays topology information.
switch# show topology
FC Topology for VSAN 1 :
--------------------------------------------------------------------------------
Interface Peer Domain Peer Interface Peer IP Address
--------------------------------------------------------------------------------
fc1/1 0xef(239) fc2/15 172.22.46.220
fc1/5 0xe6(230) fc1/5 172.22.46.222
fc1/6 0xe6(230) fc1/6 172.22.46.222
fc1/7 0xe6(230) fc1/7 172.22.46.222
fc1/8 0xe3(227) fc1/1 172.22.46.233
fc1/10 0xe6(230) fc1/10 172.22.46.222
fc1/11 0xe6(230) fc1/11 172.22.46.222
fc1/12 0xe6(230) fc1/12 172.22.46.222
fc1/13 0xe6(230) fc1/13 172.22.46.222
fc1/14 0xe6(230) fc1/14 172.22.46.222
fc1/15 0xe6(230) fc1/15 172.22.46.222
fc1/16 0xe6(230) fc1/16 172.22.46.222
fcip2 0xef(239) fcip2 172.22.46.220
FC Topology for VSAN 73 :
--------------------------------------------------------------------------------
Interface Peer Domain Peer Interface Peer IP Address
--------------------------------------------------------------------------------
fc1/1 0x65(101) fc2/15 172.22.46.220
fcip2 0x65(101) fcip2 172.22.46.220
vsan vsan-id Displays information for a VSAN. The range is 1 to 4093.
Release Modification
2.0(x) This command was introduced.
