Cisco MDS 9000 Series Command Reference

Send documentation comments to mdsfeedback-doc@cisco.com
21-4
Cisco MDS 9000 Family Command Reference
OL-8413-07, Cisco MDS SAN-OS Release 3.x
Chapter 21 S Commands
santap module
santap module
To configure the mapping between the Storage Services Module (SSM) and the VSAN where the
appliance is configured, use the santap module command in configuration mode. To disable this feature,
use the no form of the command.
santap module slot-number {appl-vsan vsan-id [cvt-name cvt-name] |
dvt target-pwwn target-pwwn target-vsan target-vsan-id dvt-name dvt-name dvt-vsan
dvt-vsan-id [dvt-port port-number] [lun-size-handling enable/disable] [io-timeout
timeout-value]}
no santap module slot-number {appl-vsan vsan-id [cvt-name cvt-name] |
dvt target-pwwn target-pwwn}
Syntax Description
Defaults Disabled.
The IO-timeout is 10 seconds.
Lun-size-handling is Enabled.
Command Modes Configuration mode.
slot-number Specifies the slot number of the SSM where the control virtual target (CVT) is
created.
appl-vsan vsan-id Specifies the appliance VSAN identification number used to communicate
with the appliance. The range is 1 to 4093.
cvt-name cvt-name Specifies the control virtual target (CVT) name. The maximum size is 80
characters.
dvt Configures the data virtual target (DVT).
target-pwwn
target-pwwn
Specifies the target pWWN for the DVT. The format is
hh:hh:hh:hh:hh:hh:hh:hh.
target-vsan
target-vsan-id
Specifies the target VSAN for the DVT. The range for the real target-vsan-id
is 1 through 4093.
dvt-name dvt-name Specifies the DVT name. The maximum size is 80 characters.
dvt-vsan dvt-vsan-id
Specifies the DVT VSAN. The range for the dvt-vsan-id is 1 through 4093.
dvt-port port-number Specifies the DVT port. The range for the port number is 1 through 32.
lun-size-handling
enable/disable
Enables or disables LUN size handling. Specify 1 to enable or 0 to disable
LUN size handling, with the default being enable.
io-timeout
timeout-value
Specifies the I/O timeout value. The range is 10 to 200 seconds, with the
default being 10 seconds.
