Chapter 27 Z Commands
zone name (configuration mode)
Use the show wwn switch command to retrieve the sWWN. If you do not provide a sWWN, the software
automatically uses the local sWWN.
Broadcast frames are sent to all Nx ports.
If any NL port attached to an FL port shares a broadcast zone with the source of the
broadcast frame,
then the frames are broadcast to all devices in the loop.
Examples The following example configures attributes for the specified zone (Zone1) based on the member type
(pWWN, fabric pWWN, FCID, or FC alias) and value specified.
switch# config terminal
switch(config)# zone name Zone1 vsan 10
switch(config-zone)# attribute broadcast
switch(config-zone)# attribute read-only
The following example configures members for the specified zone (Zone2) based on the member type
(pWWN, fabric pWWN, FCID, or FC alias) and value specified.
switch# config terminal
switch(config)# zone name Zone2 vsan 10
switch(config-zone)# attribute broadcast
switch(config-zone)# attribute read-only
pWWN example:
switch(config-zone)# member pwwn 10:00:00:23:45:67:89:ab
Fabric pWWN example:
switch(config-zone)# member fwwn 10:01:10:01:10:ab:cd:ef
FC ID example:
switch(config-zone)# member fcid 0xce00d1
FC alias example:
switch(config-zone)# member fcalias Payroll
Domain ID example:
switch(config-zone)# member domain-id 2 portnumber 23
FC alias example:
switch(config-zone)# member ipaddress 10.15.0.0 255.255.0.0
Local sWWN interface example:
switch(config-zone)# member interface fc 2/1
Remote sWWN interface example:
switch(config-zone)# member interface fc2/1 swwn 20:00:00:05:30:00:4a:de
Domain ID interface example:
switch(config-zone)# member interface fc2/1 domain-id 25
Related Commands Command Description
show zone Displays zone information.
zone rename Renames zones.
zone-attribute-group
name
Configures zone attribute groups.
