Hioki 8841 - Page 10

Chapter 13 Printout of Measurement Data 283
13.1 Printout of Measurement Data Operating
Procedure
284
13.2 Setting the STATUS Screen (printout)
286
13.2.1 Setting the Display Format 286
13.2.2 Setting the Print Mode
287
13.3 Setting the CHANNEL Screen (printout) 288
13.3.1 Setting the Print Density 288
13.3.2 Setting the Waveform Display Graph Position 289
13.4 Setting the SYSTEM Screen (printout) 290
13.4.1 SET UP Screen (SYSTEM 1) 290
13.4.2 SCALING Screen (SYSTEM 2) 292
13.4.3 COMMENT Screen (SYSTEM 3)
292
13.4.4 Setting the Output Destination by the COPY
Key
293
13.4.5 Setting the Output Destination by the PRINT
Key 294
13.5 Example of Printer Output 296
13.6 Printing Procedure
303
13.6.1 Manual Print 303
13.6.2 Auto Print 304
13.6.3 Real Time Print 305
13.6.4 Partial Print 306
13.6.5 Screen Hard Copy 307
13.6.6 List Print 307
13.6.7 Report Print 307
13.7 External Printer (color print) 308
Chapter 14 Storing Measurement Data 311
14.1 Floppy Disk 312
14.2 9607 MO UNIT (Option)
313
14.2.1 Setting the Internal MO 314
14.3 PC Card 315
14.3.1 Using the PC Card Slot (PC Card with a
Cable Only) 316
14.4 SCSI Interface 317
14.4.1 SCSI Interface Specifications 317
14.4.2 Setting the MO Disk Drive
318
14.4.3 Setting the SCSI ID
319
14.5 Selecting the Media Type 320
14.6 Initializing (FORMAT)
321
14.7 Saving the Data (SAVE)
322
