Setting Description
LogicTrigger
Creates a trigger model that waits on an input line, delays, makes a measurement,
and sends out a trigger on the output line a specified number of times.
Settings that you can change before generating the trigger model:
 Input Line (default 1)
 Output Line (default 2)
 Count (default 10)
 Delay (default 0.001 s)
 Trigger Clear (default Never)
 Reading Buffer (default
defbuffer1
)
LoopUntilEvent
Creates a trigger model that makes continuous measurements until a specified
event occurs. Settings that you can change before generating the trigger model:
 Source Event (default Trigger Key)
 Position (default 50%)
 Delay (default 0.001 s)
 Reading Buffer (default defbuffer1)
 Trigger Clear (default Enter)
SimpleLoop
Creates a trigger model that sets up a loop that sets a delay, makes a
measurement, and then repeats the loop the number of times you define in the
count parameter.
Settings that you can change before generating the trigger model:
 Count (default 10)
 Delay (default 0.001 s)
 Reading Buffer (default defbuffer1)
SortBinning
Creates a trigger model that successively measures components and compares
their readings to high or low limits to sort components.
