Section
4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument R
eference Manual
4-88 2470-901-01 Rev. A / May 2019
Measure configuration list settings
Front-panel setting SCPI command
TSP command
User delay (1 through 5)
Not available from front panel
[:SENSe[1]]:<function>:DELay:USER<n> (on page
12-47)
smu.measure.userdelay[N] (on page 14-149)
Instrument settings stored in a source configuration list
When you save a configuration index to a source configuration list, the instrument saves the values
for each setting listed in the following table. These settings can be set from the front panel or by using
remote commands. The table lists SCPI and TSP commands that can be used to set these settings.
Source configuration list settings
Front-panel setting SCPI command
TSP command
Auto delay
Not available from the front panel
:SOURce[1]:<function>:DELay:AUTO (on page 12-74)
smu.source.autodelay (on page 14-152)
Auto range
HOME > Source Range
:SOURce[1]:<function>:RANGe:AUTO (on page 12-83)
smu.source.autorange (on page 14-151)
Delay
MENU > Source > Settings > Source Delay
:SOURce[1]:<function>:DELay (on page 12-73)
smu.source.delay (on page 14-159)
Function
FUNCTION key
:SOURce[1]:FUNCtion[:MODE] (on page 12-80)
smu.source.func (on page 14-160)
High capacitance
MENU > Source > Settings > High Capacitance
:SOURce[1]:<function>:HIGH:CAPacitance (on page
12-76)
smu.source.highc (on page 14-160)
Limit
HOME > Limit
:SOURce[1]:<function>:<x>LIMit[:LEVel] (on page 12-78)
smu.source.xlimit.level (on page 14-177)
Output off state
MENU > Source > Settings > Output Off State
:OUTPut[1]:<function>:SMODe (on page 12-37)
smu.source.offmode (on page 14-162)
Overvoltage protection
MENU > Source > Settings > Overvoltage
Protection Limit
:SOURce[1]:<function>:PROTection[:LEVel] (on page
12-80)
smu.source.protect.level (on page 14-164)
Range
MENU > Source > Settings > Source Range
:SOURce[1]:<function>:RANGe (on page 12-82)
smu.source.range (on page 14-166)
Readback
MENU > Source > Settings > Source Readback
:SOURce[1]:<function>:READ:BACK (on page 12-84)
smu.source.readback (on page 14-167)
Source level
HOME > Source
:SOURce[1]:<function>:<x>LIMit[:LEVel] (on page 12-78)
smu.source.level (on page 14-161)
User delays
Not available from the front panel
:SOURce[1]:<function>:DELay:USER<n> (on page
12-75)
smu.source.userdelay[N] (on page 14-176)
