4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument
4-96 2470-901-01 Rev. A / May 2019
The following topics provide information to:
• Create an example source configuration list named MySourceList.
• Store four example configuration indexes on MySourceList.
• View the contents of a specific configuration index.
• Recall a configuration index from MySourceList.
The following table provides information about specific settings for each configuration index.
Settings Index 1 Index 2 Index 3 Index 4
The figures in this section include a graphic representation of MySourceList and the four
configuration indexes. For simplicity, the figures will only show two of the source settings listed in the
table (source range and source level).
This example creates a source configuration list; however, you can use the same process to create a
measure configuration list.
Creating a configuration list and giving it a name
Use one of the following methods to create the configuration list used in this example and give it a
name.
Using SCPI commands:
:SOURce:CONFiguration:LIST:CREate "MySourceList"
Using TSP commands:
smu.source.configlist.create("MySourceList")
