High Voltage SourceMeter Instrument Reference Manual Section 5: Source-
measure considerations
2470-901-01 Rev. A / May 2019 5-31
Measurement reset values
Setting
Default value on
reset
Menu > Measure > Config List > New List
[:SENSe[1]]:CONFiguration:LIST:CREate (on page 12-61)
smu.measure.configlist.create() (on page 14-115)
None (existing
configuration lists
deleted)
Menu > Measure > Config List > System to Index
[:SENSe[1]]:CONFiguration:LIST:STORe (on page 12-65)
smu.measure.configlist.store() (on page 14-120)
None (existing
configuration lists
deleted)
Menu > Measure > Settings > Count
[:SENSe[1]]:COUNt (on page 12-66)
smu.measure.count (on page 14-121)
1
SETTINGS swipe > Auto Zero
[:SENSe[1]]:<function>:AZERo[:STATe] (on page 12-46)
smu.measure.autozero.enable (on page 14-113)
On
Not available from front panel
[:SENSe[1]]:<function>:DELay:USER<n> (on page 12-47)
smu.measure.userdelay[N] (on page 14-149)
0
MENU > Measure > Settings > Offset Compensation
(when instrument is set to source current and measure
resistance)
[:SENSe[1]]:<function>:OCOMpensated (on page 12-49)
smu.measure.offsetcompensation (on page 14-140)
Off
SETTINGS swipe > NPLCs
[:SENSe[1]]:<function>:NPLCycles (on page 12-48)
smu.measure.nplc (on page 14-139)
1
FUNCTION key
[:SENSe[1]]:FUNCtion[:ON] (on page 12-67)
smu.measure.func (on page 14-127)
Current
HOME > Range
[:SENSe[1]]:<function>:RANGe:AUTO (on page 12-50)
smu.measure.autorange (on page 14-110)
On
MENU > Measure > Settings > Auto Range Low Limit
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit
(on page
12-51)
smu.measure.autorangelow (on page 14-112)
Current: 10 nA
Voltage: 200 mV
Resistance: 2 Ω
Not available from front panel
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit (on page
12-52)
smu.measure.autorangehigh (on page 14-111)
Resistance:
200 MΩ
HOME > Measure Range
[:SENSe[1]]:<function>:RANGe[:UPPer] (on page 12-53)
smu.measure.range (on page 14-141)
AUTO
Not available from front panel
[:SENSe[1]]:<function>:RELative (on page 12-55)
smu.measure.rel.level (on page 14-146)
0
MENU > Measure > Calculations > Rel
[:SENSe[1]]:<function>:RELative:STATe (on page 12-57)
smu.measure.rel.enable (on page 14-145)
Off
MENU > Measure > Settings > Sense
[:SENSe[1]]:<function>:RSENse (on page 12-58)
smu.measure.sense (on page 14-147)
2-wire
