5: Source-measure considerations 2470 High Voltage SourceMeter Instrument
Reference Manual
5-32 2470-901-01 Rev. A / May 2019
Setting
Default value on
reset
Not available from front panel
[:SENSe[1]]:<function>:UNIT (on page 12-59)
smu.measure.unit (on page 14-148)
Current: Amp
Voltage: Volt
Source reset values
Setting
Default value on
reset
Menu > Source > Config List > New List
:SOURce[1]:CONFiguration:LIST:CREate (on page 12-68)
smu.source.configlist.create() (on page 14-153)
None (existing
configuration lists
deleted)
Menu > Source > Config List > System to Index
:SOURce[1]:CONFiguration:LIST:STORe (on page 12-72)
smu.source.configlist.store() (on page 14-158)
None (existing
configuration lists
deleted)
Not available from front panel
:SOURce[1]:<function>:DELay:AUTO (on page 12-74)
smu.source.autodelay (on page 14-152)
On
MENU > Source > Settings > High Capacitance
:SOURce[1]:<function>:HIGH:CAPacitance (on page 12-76)
smu.source.highc (on page 14-160)
Off
HOME > Source
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude] (on
page 12-77)
smu.source.level (on page 14-161)
0
HOME > Limit
:SOURce[1]:<function>:<x>LIMit[:LEVel] (on page 12-78)
smu.source.xlimit.level (on page 14-177)
Current: 105 µA
Voltage: 21 V
FUNCTION key
:SOURce[1]:FUNCtion[:MODE] (on page 12-80)
Not applicable for TSP
Current
MENU > Source > Settings > Overvoltage Protection
:SOURce[1]:<function>:PROTection[:LEVel] (on page
12-80)
smu.source.protect.level (on page 14-164)
None
MENU > Source > Settings > Source Range
:SOURce[1]:<function>:RANGe (on page 12-82)
smu.source.range (on page 14-166)
Current: 10 nA
Voltage: 200 mV
HOME > Source Range
:SOURce[1]:<function>:RANGe:AUTO (on page 12-83)
smu.source.autorange (on page 14-151)
On
MENU > Source > Settings > Source Readback
:SOURce[1]:<function>:READ:BACK (on page 12-84)
smu.source.readback (on page 14-167)
On
FUNCTION
key
:SOURce[1]:FUNCtion[:MODE] (on page 12-80)
smu.source.func (on page 14-160)
Voltage
