Tektronix Keithley SourceMeter 2470 Reference Manual

2470
High Voltage SourceMeter Instrument Reference Manual Section 5: Source-measure
considerations
2470-901-01 Rev. A / May 2019 5-33
Buffer reset values
Setting
Default value on
reset
Not available from front panel
:TRACe:FILL:MODE (on page 12-125)
bufferVar.fillmode (on page 14-23)
Default buffers:
Continuous
User-defined
buffers: Once
Not available from front panel
:TRACe:LOG:STATe (on page 12-126)
bufferVar.logstate (on page 14-26)
Default buffers: ON
User-created
buffers: OFF
Trigger reset values
Setting
Default value on
reset
Not available from front panel
:TRIGger:BLENder<n>:MODE (on page 12-144
)
trigger.blender[N].orenable (on page 14-193)
AND
Not available from front panel
:TRIGger:DIGital<n>:IN:EDGE (on page 12-171)
trigger.digin[N].edge (on page 14-199)
Falling edge
Not available from front panel
:TRIGger:DIGital<n>:OUT:LOGic (on page 12-173)
trigger.digout[N].logic (on page 14-202)
Negative
Not available from front panel
:TRIGger:DIGital<n>:OUT:PULSewidth (on page 12-174)
trigger.digout[N].pulsewidth (on page 14-203)
10e-6 s
Not available from front panel
:TRIGger:DIGital<n>:OUT:STIMulus (on page 12-174)
trigger.digout[N].stimulus (on page 14-204)
None
Not available from front panel
:TRIGger:LAN<n>:IN:EDGE (on page 12-176)
trigger.lanin[N].edge (on page 14-206)
Either edge
Not available from front panel
:TRIGger:LAN<n>:OUT:IP:ADDRess (on page 12-178)
trigger.lanout[N].ipaddress (on page 14-211)
0.0.0.0
Not available from front panel
:TRIGger:LAN<n>:OUT:PROTocol (on page 12-179)
trigger.lanout[N].protocol (on page 14-212)
TCP
Not available from front panel
:TRIGger:LAN<n>:OUT:STIMulus (on page 12-180)
trigger.lanout[N].stimulus (on page 14-213)
None
Not available from front panel
:TRIGger:TIMer<n>:COUNt (on page 12-192)
trigger.timer[N].count (on page 14-252)
1
Not available from front panel
:TRIGger:TIMer<n>:DELay (on page 12-194)
trigger.timer[N].delay (on page 14-253)
10e-6 s
