5: Source-measure considerations 2470 High Voltage SourceMeter Instrument
Reference Manual
5-34 2470-901-01 Rev. A / May 2019
Setting
Default value on
reset
Not available from front panel
:TRIGger:TIMer<n>:STARt:FRACtional (on page 12-194)
trigger.timer[N].start.fractionalseconds (on page 14-257)
0
Not available from front panel
:TRIGger:TIMer<n>:STARt:GENerate (on page 12-195)
trigger.timer[N].start.generate (on page 14-257)
Off
Not available from front panel
:TRIGger:TIMer<n>:STARt:SEConds (on page 12-196)
trigger.timer[N].start.seconds (on page 14-259)
0
Not available from front panel
:TRIGger:TIMer<n>:STARt:STIMulus (on page 12-197)
trigger.timer[N].start.stimulus (on page 14-259)
No event
Not available from front panel
:TRIGger:TIMer<n>:STATe (on page 12-198)
trigger.timer[N].enable (on page 14-255)
Off
Not available from front panel
Not applicable for SCPI
trigger.tsplinkin[N].edge (on page 14-262)
Falling
Not available from front panel
Not applicable for SCPI
trigger.tsplinkout[N].logic (on page 14-265)
Negative
Not available from front panel
Not applicable for SCPI
trigger.tsplinkout[N].pulsewidth (on page 14-266)
10e-6 s
TSP-Link and TSP-Net reset values
Setting
Default value on
reset
Not available from front panel
Not applicable for SCPI
tsplink.line[N].mode (on page 14-271)
Digital open drain
Not available from front panel
Not applicable for SCPI
tspnet.timeout (on page 14-284)
20
Not available from front panel
Not applicable for SCPI
tspnet.tsp.abortonconnect (on page 14-285)
1
