6: Reading buffers 2470 High Voltage SourceMeter Instrument
6-22 2470-901-01 Rev. A / May 2019
Using the front panel to save buffer content to files:
1. Insert a USB flash drive into the USB port.
2. Press the MENU key.
3. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
4. Select the reading buffer that you want to save. For example, select testData.
Figure 120: MANAGE READING BUFFERS window
5. Select Save To USB.
6. A keyboard is displayed.
7. Enter the name of the file in which to save the readings.
You only need to enter the name of the file you want to save. It is not necessary to enter the file
extension. All files are saved as CSV files.
8. Select OK on the keyboard.
9. Select OK to save the file. When the MANAGE READING BUFFERS window is displayed again,
the file is saved.
10. Press the HOME key to return to the home screen.
