2: Installation 2470 High Voltage SourceMeter Instrument Reference
2-34 2470-901-01 Rev. A / May 2019
See the following figure for an example of the virtual front panel.
Figure 25: Virtual front panel
Change the date and time through the web interface
You can change the instrument date and time through the web interface. This is the same as
changing the date and time through the front-panel System Settings menu. The date and time is used
for the event log entries and data timestamps.
To change the date and time:
1. From the web interface page, select Admin.
2. In the Local time table, change the information as needed.
3. Click Submit.
