13: Introduction to TSP commands 2470 High Voltage SourceMeter Instrument
13-40 2470-901-01 Rev. A / May 2019
9. Click Apply.
10. Click the Script Attributes tab.
11. Select one of the following:
 Load and Execute: If you select this option, which is the default selection, the scrip
t
aut
omatically loads into the instrument's volatile memory (run-time environment)
and
ex
ecutes when you click Run.
 Load: If you select this option, the script is loaded into the instrument's volatile memory whe
n
yo
u click Run, but is not executed until you manually run it. To manually run it from t
he
c
ommand line in the Instrument Console, type MyConfiguration.run() (where
MyConfiguration is the name of your configuration).
Figure 150: Script Attributes tab
12. In the Storage area of the Script Attributes tab, select Volatile or Non-volatile. For products that
support autorun scripts, if you select Non-volatile, you can select Auto Run to have the script r
un
aut
omatically when the instrument is turned on.
Note that all scripts are initially stored in the volatile (runtime) memory of the instrument memory
and are lost if you turn the instrument power off and then on again. If you want to keep the script
on the instrument through a power cycle, select Non-volatile storage.
13. In the Debug area of the Script Attributes tab, you can select Generate Debug File.
When you select this option, a Debug subfolder is created in your test folder, and a file wit
h
a .DBG
extension is created in that folder. Note that this is a feature of the Eclipse platform, an
d
y
ou will not use this file to debug your script. It contains all the scripts in your run configuration, s
o
that you can see them together in the order in which they will load.
14. Click Close or Run. The run configuration is added to the run configurations list.
