Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-29
Error Messages and Codes
116 210 USB Host Error
Error 116-210
Restart Printer
<USB Host Error>
Fatal error of USB Host driver
page
44
315 RAM Error
Error 116-315
Restart Printer
<ESS On Board RAM R/W Check Fail>
An error occurred during the on board
RAM read/write check at the time of
initialization.
page
44
This code is given when the Optional 512MB Memory is installed.
316 RAM Error
Error 116-316
Restart Printer
<ESS DIMM Slot RAM R/W Check Fail>
Unsupported additional memory module
is detected in the memory slot.
page
160
317 Controller Error
Error 116-317
Restart Printer
<ESS ROM Check (Main) Fail>
Checksum error occurred in the main
program ROM.
page
44
This code is given when the Optional 512MB Memory is installed.
320 RAM Error
Error 116-320
Restart Printer
<ESS DIMM Slot RAM Error>
Additional memory module is not
completely inserted in the slot.
page
160
323 NV RAM Error
Error 116-323
Restart Printer
<ESS NVRAM 1 R/W Check Fail>
An error occurred during the master
NVRAM 1 read/write check at the time of
initialization.
page
44
324 Controller Error
Error 116-324
Restart Printer
<ESS Illegal Exception>
An Exception error occurred.
page
44
326 NV RAM Error
Error 116-326
Restart Printer
<ESS NVRAM 2 R/W Check Fail>
An error occurred during the slave
NVRAM 2 read/write check at the time of
initialization.
(Reserved)
page
44
327 Controller Error
Error 116-327
Restart Printer
<ESS Instruction Cache Error>
A CPU instruction cache error occurred.
page
44
328 Controller Error
Error 116-328
Restart Printer
<ESS Data Cache Error>
A CPU cache error occurred.
page
44
343 ASIC Error
Error 116-343
Restart Printer
<ESS ASIC Fail>
An ASIC error occurred.
page
44
350 Network Error
Error 116-350
Restart Printer
<ESS Network Communication Fail>
A communication error occurred between
the On Board Network and IP Board
firmware.
page
44
Error Code List & Error Message Summary (continued)
Error Code
Error Message
LCD
Error Description Go To

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
