Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 8-101
Service Parts Disassembly
15. Remove the Fuser and Interlock Switch harnesses from the guide.
16. Release the 4 hooks to remove the guide from the LVPS Frame.
s6500-26
9
Fuser2 Harness
Interlock Harness
Front
Hook
Tab
Hook
Front
