Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-388 Issue 4 May 2002
Field descriptions
The following display shows the call’s audio is being IP Media Processor
ip-hairpinned through a TN2302 Prowler board on this switch.
If the station’s audio is connected ip-ip directly from the station to the far end
destination, the audio port shown on page 3 equals the station port shown on
page 1.
Field descriptions
Part ID Number
Shows the Part ID Number (comcode) of the telephone. If this
field shows Unavailable, then the software was unable to
determine the Part ID Number.
Serial Number
This is the serial number of the telephone. This field may
show Unavailable if the software is unable to determine the
Serial Number.
This field can also show Errored if the serial number received
is not in the correct format.
Station Lock
Active
Indicates whether the station has been locked using Station
Lock.
Mac Address
The MAC (Media Access Control) address field shows the
MAC address received from the IP phone when the phone
registers. If the phone registers but is unable to send a MAC
address then the field shows “not available”. The field is blank
if the phone is not registered.
status station Page 3 of X
CALL CONTROL SIGNALING
Switch IP
Port Switch-end IP Addr: Port Set-end IP Addr:Port
IP Signaling: : :
H.245:
Node Name:
AUDIO CHANNEL
Switch IP
Port Other-end IP Addr: Port Set-end IP Addr:Port
Audio:
Node Name:
Audio Connection Type: ip-tdm
Product ID: IP_Phone
H.245 Tunneled in Q.931? does not apply
Registration Status: registered-authenticated
MAC Address: 00:20:fc:le:13:f9
