Maintenance Object Repair Procedures
555-233-123
10-1962 Issue 4 May 2002
LAN cable
The TN2501AP circuit pack does not include cables to connect the circuit pack to
your LAN. The following table lists the cable category and connection port.
Maintenance Commands
The following table lists several VAL-related maintenance commands and how to
use the command for troubleshooting.
Ethernet connection speed Cable Connection description
10 Mbps Category 3 Connects through the RJ45 jack
(note #2 in Figure 10-106),
100 Mbps Category 5 Connects through the RJ45 jack
(note #2 in Figure 10-106),
Table 10-702. VAL maintenance commands
Command Use this command to
test board Test both circuit pack- and port-level maintenance.
test port Test any of the ports on the VAL circuit pack
test mo Test either of the 2 maintenance objects on the VAL circuit pack
busyout board Curtail activity on the circuit pack before resetting it (reset board).
release board Resume activity on the circuit pack after busying out the VAL circuit
pack or ports on it (busyout board or busyout port).
busyout port Isolate a specific port usually during troubleshooting.
release port Resume activity after busying out a port on the VAL circuit pack
(busyout port).
reset board Re-initialize the circuit pack in the system and upload
announcement file information.
reset val Reset the circuit pack if it is in the insane state and to override
querying the board to determine if an announcement autosave is in
process.
status data-module Obtain general information about the data-module connection to
port 33 on the VAL circuit pack
status firmware download Obtain information about a demand or scheduled firmware
download.
list sys-link Generate a list of administered links and the general status of each.
status sys-link Generate a detailed status report for a specific administered system
link.
status link Generate a status report about a specific administered ethernet
link. (For VAL this means the administered ethernet link.)
Continued on next page
