Avaya Definity SI - H323-SGRP (H.323 Signaling Group)

Maintenance Object Repair Procedures
555-233-123
10-872 Issue 4 May 2002
H323-SGRP (H.323 Signaling Group)
The maintenance object H.323 Signaling Group (H323-SGRP) supports a
signaling channel (D-Channel) for H.323 Trunk connections. The MedPro TN802
circuit pack provides audio connectivity, working in concert with a C-LAN (TN799)
circuit pack which provides control signaling to support an H.323 connection.
The H.323 signaling group (H323-SGRP) is a signaling channel that physically
resides on a C-LAN port (socket) and the IP network. Unlike ISDN D-channels,
the H.323 channel may come up and down on a call by call basis. The H.323
channel is a TCP/IP signaling channel. Layers 1 and 2 of this signaling channel
are monitored by IP PING testing.
Error Log Entries and Test to Clear Values
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
MO Name (in
Alarm Log) Alarm Level
Initial Command to
Run
1
1 grp# is the signaling group number (1-166); the test sequence can be either short or long.
Full Name of MO
H323-SGRP MINOR test sig-group grp# H323 Signaling Group
H323-SGRP WARNING test sig-group grp# H323 Signaling Group
Table 10-314. H323-SGRP Signaling Group Error Log Entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
0 Any Any test sig-group grp#
1 (a) Any Ethernet Port Status Test
#1386
MINOR OFF test sig-group grp#
257 (b) Any H.323 SGRP PING Test
#1387
MINOR OFF test sig-group grp#
513(c) Any H.323 SGRP PING Test
#1387
WARNING OFF test sig-group grp#
770(d) Any WARNING OFF
1025(e) Any MEDPRO Status Test #1392 MINOR OFF test sig-group grp#
1281(f) Any MEDPRO Status Test #1392 MINOR OFF
1794(g) MEDPRO Status Test #1392 MINOR OFF test sig-group grp#
2049(h) Keep Alive Failure MINOR OFF test sig-group grp#
2305(i) Gateway Unregistered MINOR OFF test sig-group grp#
