Avaya Definity SI - Bri-Set, Asai-Adj, Bri-Dat

Maintenance Object Repair Procedures
555-233-123
10-292 Issue 4 May 2002
BRI-SET, ASAI-ADJ, BRI-DAT
!
CAUTION:
A detailed flowchart for isolating and resolving Packet Bus faults is included
in Chapter 9, “Packet Bus Fault Isolation and Correction”. This flowchart,
along with the other information presented in the chapter, can help in
resolving problems that involve more than a single station or circuit pack.
Whenever the repair procedures for this Maintenance Object refer to Packet
Bus and/or Packet Control maintenance, be sure to reference Chapter 9,
“Packet Bus Fault Isolation and Correction” in addition to the relevant MO
documentation.
MO Name (in
Alarm Log) Alarm Level Initial Command to Run
1
1 Where P is the port network number (1 for PPN and 2 or 3 for EPN); C is the carrier designation (A,
B, C, D, or E); SS is the address of the slot in the carrier where the circuit pack is located (01, 02,
etc.); and pp is the 2-digit port number (for example, 01). The alternate name field contains the
extension of the endpoint. This field is used to distinguish between endpoints on the same port.
Full Name of MO
BRI-SET WARNING
2
2 The alarm level for ASAI and Avaya adjuncts may be administered using the set options command.
The alarm level can be set independently for Off-Board and On-Board alarms to WARNING,
MINOR, or MAJOR for all ASAI and Avaya adjuncts in the system.
test station extension l,
test data-module extension
ISDN-BRI Set
ASAI-ADJ MAJOR
2
test station extension ASAI-Adjunct
ASAI-ADJ MAJOR
2
test data-module extension ASAI-Adjunct
ASAI-ADJ WARNING
3
3 Alarming for an ASAI and Avaya adjuncts is disabled if the adjunct asks the switch to suspend
maintenance. When this occurs, an error and a WARNING alarm are logged against the endpoint.
Busying out and releasing the ASAI station or ADJLK station will clear the alarm.
test data-module extension ASAI-Adjunct
ATT-ADJ MAJOR
2
test station extension Avaya-Adjunct
ATT-ADJ MAJOR
2
test station extension Avaya-Adjunct
ATT-ADJ WARNING
3
test station extension Avaya-Adjunct
LGATE-AJ MAJOR
2
test station extension Ethernet ASAI-Adjunct
LGATE-AJ MAJOR
2
test station extension Ethernet ASAI-Adjunct
LGATE-AJ WARNING
3
test station extension Ethernet ASAI-Adjunct
ATTE-AJ MAJOR
2
test station extension Ethernet Avaya-Adjunct
ATTE-AJ MAJOR
2
test station extension Ethernet Avaya-Adjunct
ATTE-AJ WARNING
3
test station extension Ethernet Avaya-Adjunct
BRI-DAT test data-module
