VC-SUMPT
Issue 4 May 2002
10-1987 555-233-123
VC-SUMPT
Each Voice Conditioner Circuit Pack (VC-BD) provides two types of resources:
1. Transcoder Resources that are used for encoding and decoding audio
formats
2. Summer Resources that are used for summing audio formats from different
sources.
The Voice Conditioner Summer ports (VC-SUMPT) are the summer resources on
the VC-BD. There are 8 such ports on a VC-BD.
Error Log Entries and Test to Clear Values
MO Name (in
Alarm Log)
Alarm
Level
Initial Command to
Run
1
1 Where UU is the universal cabinet number (1 for PPN and 2-3 for EPN); C is the carrier
designation (for example, A, B, C, D, or E); SS is the address of the slot in the carrier
where the circuit pack is located (for example, 01, 02, ...); and pp is the two digit port
number (01, 02, 03, ...).
Full Name of MO
VC-SUMPT MAJ test port PCSS l r# Voice Conditioner Summer Port
VC-SUMPT MIN test port PCSS l r# Voice Conditioner Summer Port
VC-SUMPT WNG test port PCSS s r# Voice Conditioner Summer Port
Table 10-714. VC-SUMPT Error Log Entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the short test sequence first. If all test pass, run the long test sequence. Refer to the appropriate
test description and follow the recommended procedures.
0 Any Any Any test port PCSSpp sh r 1
18 (a) 0 busyout port PCSS WNG OFF release port PCSSpp
130 (b) WNG ON test port PCSSpp sh
257 (c) Any Control Channel Loop
Test (#52)
MIN ON test board PCSSpp 1 r 3
513 (d) Any VC Summer Port Local
Loopback Test #(1100)
MIN ON test board PCSSpp sh r 3
