Maintenance Object Repair Procedures
555-233-123
10-696 Issue 4 May 2002
DTMR-PT [Dual Tone Multifrequency
Port (TTR)]
The Dual Tone Multifrequency Receiver Port (DTMR), also known as the
Touch-Tone Receiver (TTR), resides on the Tone Detector circuit pack (TN748,
TN420) or the TN756 Tone-Clock circuit pack. There are four Dual Tone
Multifrequency Receiver (DTMR-PT) ports and two General Purpose Tone
Detector (GPTD-PT) ports on a Tone Detector circuit pack. The DTMR port is
used to detect touch-tone digits that are placed on the TDM bus. Examples of
touch-tone digits are digits 0 through 9, digit #, and digit *. The ability of the DTMR
port to detect touch-tone digits is essential for maintenance of other circuit packs
(for example, Tone-Clock circuit pack) and in placing a station-to-station call. Calls
originating from a hybrid station do not require a DTMR port.
The Dual Tone Multifrequency Receiver Port maintenance object defines a set of
tests to verify that the DTMF digits detection capability of the DTMR port is
functioning properly. For all Tone Detector circuit pack level errors (DETR-BD),
refer to the XXX-BD (Common Port Circuit Pack) Maintenance documentation.
MO Name (in
Alarm Log)
Alarm
Level
Initial Command to
Run
1
1 Where P is the port network number (1 for PPN and 2 or 3 for EPN); C is the carrier
designation (for example, A, B, C, D, or E); SS is the address of the slot in the carrier
where the circuit pack is located (for example, 01, 02, etc.); and pp is the 2-digit port
number (for example, 01).
Full Name of MO
DTMR-PT MAJOR test port PCSSpp sh Dual Tone Multifrequency
Receiver Port (TTR)
DTMR-PT MINOR test port PCSSpp sh Dual Tone Multifrequency
Receiver Port (TTR)
DTMR-PT WARNING release port PCSSpp Dual Tone Multifrequency
Receiver Port (TTR)
