SHOP MANUAL
Engine
Ch 1 page 78
Cylinder configuration, 5 cylinder engines
It is a good idea to mark the rocker arm with a pen after adjustment to keep
track of what has already been adjusted.
The flywheel also has markings at 240°/600° and 120°/480°, these mark-
ings apply to 6 cylinder engines.
Rev-
olu-
tion
Valve
change
on cylin-
der
Adjust intake
and exhaust
valves on cyl-
inder
Mark on fly-
wheel. Read-
ing in the up-
per window
1 1 TDC Up
1 5 252/612
1 2 324/684
1 3 36/396
1 4 108/468
2 1 TDC Up
2 5 252/612
2 2 324/684
2 3 36/396
2 4 108/468
Figure 145
