Doosan DA40 - Transmission temperature sensors

SHOP MANUAL
Ch 6 page 76
ELECTRICAL SYSTEM
270
270
900
NB.
ZF position
number
Temperature
sensor
oil out to
cooler
Resistance at
20°C 61465 Ω
Temperature sensor
oil in from cooler
Resistance at
20°C 61465 Ω
Left Hand side
Clutch pressure
controller
(Solenoid valve)
Resistance at 20°C 11 Ω
The temperature sensor oil out from transmission is placed
inside converter housing.
Remove plug vith 24 mm Allen screw key
Transmission temperature sensors
Figure 66
Figure 65
Figure 67
