Doosan DA40 - XPI Fuel system DA30;40

SHOP MANUAL
Engine
Ch 1 page 18
Scania XPI
High Pressure Connectors
Fuel Manifold
Fuel Heater
350W 5-24 deg
Hand Pump
Inlet Metering Valve
Low Pressure Pump
High Pressure Pump
Injector
Mechaniccal Dump Valve Fuel Rail
Pressure Sensor
High Pressure
Line
Bleed
Fuel Filter 2
3 microns
Fuel Filter 1
10 microns
XPI Fuel system DA30/40
Figure 27
Figure 28
