SHOP MANUALSHOP MANUAL
FRONT WAGON
Ch 7 Page 34 Ch 7 Page 35
FRONT WAGON
Fenders, Mudguards and Bonnet are together with the hydraulic tank, diesel fuel tank and cab, the bodywork of
the dumper.
Fenders and mudguards are exposed parts which are likely to be beaten up under heavy use, and should be
replaced if damaged, as misalignment will reduce the protection for the internal parts, and reduce service life.
Damages also reduce the general appearance of the dumper.
7.4 Fenders, Mudguards and Bonnet
Fenders and Mudguards
Fender RH
Fender LH
Mudguard
LH
Inner Mud-
guard
Mudguard RH
Inner Mudguard
Hydraulic
Tank
Figure 81
To Next Page
