Doosan DA40 - System overview for mechanics

SHOP MANUAL
Engine
Ch 1 page 34
System overview for mechanics
1 Reductant tank
2 Coolant hoses for heating reductant
tank and reductant pump
3 Hydrolysis catalytic converter
4 SCR catalytic converter
Electrically
heated hoses
for reductant
Reductant
Doser
Hydrolysis catalyst
Transmission
Right
mudguard
Figure 49
Figure 50
