Doosan DA40 - Special tools

Engine
SHOP MANUAL
Ch 1 page 89
Special tools
8014 Dial gauge
8388 Filter wrench
8389 Deflection gauge
8391 Stand
8014 8388 8389 8391
1. Lubrication oil pipe
2. Ferrule
3. Union nut
4. Straight union
5. Seal
6. Straight union
7. Gasket
8. Lubrication oil return pipe
9. Hose
10. Hose clamp
11. Bolt
12. Bracket
13. Bolt
14. Clamp
15. Clamp
16. Bolt
17. Gasket
18. Turbocharger
Figure 170
Figure 171
