Doosan DA40 - Assemble the TK-diff in the axle housing

SHOP MANUAL
DRIVE LINE
Ch 3 page 106 Ch 3 page 107
DRIVE LINE
Assemble the TK-diff in the axle housing
Apply sealing compound: Loctite 574.
Apply around the threaded holes.
Assemble the differential into the axle housing.
Make sure differential is in correct position
Assemble the screws
Screw: M20x90 ISO4014-10.9 2 pcs (arrow)
Screw: M20x65 ISO4014-10.9 14 pcs
Washer: 30,8x21x4 (Nord-lock)
Apply locking liquid: Loctite 245
Be aware of personal injury.
WARNING
Figure 296
Figure 298
Figure 297
Figure 295
