Doosan DA40 - Disassembly the axle housing from the tandemhousing

SHOP MANUAL
Move tandem housing away from rear axle unit, and lower safely
to ground.
Clean the mating flanges for traces of sealing compound.
DRIVE LINE
Ch 3 page 184 Ch 3 page 185
DRIVE LINE
Safeguard the tandem housing with the crane
Disassembly the axle housing from the tandem-
housing
Lift one side of the tandem unit and place safety supports under
the axle housing.
Be sure that the tandem unit is safely placed at
the safety support.
Disassemble the wheel nut
20 pcs Width across flat: 30 mm
Take the wheel away.
Disassemble the outer screws for the bearing unit
28 pcs. M20
Be aware of personal injury.
WARNING
Figure 532
Figure 533
Figure 534
Figure 536
Figure 535
