Brake/brake charge system (Accumulators) (7)
ACC1, ACC2 and ACC3 alarm limits: 135/120bar
Max charge time: 3min
Low pressure warning -> alarm trig: Vehicle moving and/or in gear
Alarmbits1: .space 2 ; ** Brake Charge **
Sensor error on ACC3 (common/park)
Low Pressure on ACC3 (*1)
Sensor error on ACC1 (front)
Low Pressure on ACC1 (*1)
Sensor error on ACC2 (rear)
Low Pressure on ACC2 (*1)
CHARGE solenoid short circuit (NOT IMPLEMENTED YET)
CHARGE solenoid open circuit (NOT IMPLEMENTED YET)
Charge pressure not reached on ACC3
Low Pressure warning on ACC3 (*2)
Low Pressure warning on ACC1 (*2)
Low Pressure warning on ACC2 (*2)
WDB Cooling (only on DA40) (7)
Front hubs temperature warning: 93/100°C
Front hubs temperature alarm: 110/120°C
Rear tandem temperature warning: 76/80°C
Rear tandem temperature alarm: 86/90°C
Oil level alarm filter time: 3 sec
Alarmbits2: .space 2 ; ** WDB Cooling (only on DA40) **
CAN signal from rear frame
Front WDB oil level too low
Sensor error on FRONT HUBS
Too high temperature on FRONT HUBS
Sensor error on TANDEM LEFT
Too high temperature on TANDEM LEFT
Sensor error on TANDEM RIGHT
Too high temperature on TANDEM RIGHT
High temperature warning on FRONT HUBS
High temperature warning on TANDEM LEFT
High temperature warning on TANDEM RIGHT
Warning (amber,
short beep)
Alarm (red,
loud alarm)
Alarm (red,
loud alarm)
Warning (amber,
short beep)
