SHOP MANUAL
TRANSMISSION
Ch 2 page 6 Ch 2 page 7
TRANSMISSION
The structure of this Repair Manual reflects the sequence of the working steps for completely disassembling the
dismantled transmission. Dismantling and installing as well as the disassembly and assembly of a main group are
always summarized in one chapter.
Special tools required for performing the respective repair works are
listed under „Special tools“ See this chapter, 2.0
Important information on industrial safety
Generally, the persons repairing Doosan product-sets are responsible on their own for the industrial safety.
The observation of all valid safety regulations and legal impositions is the pre-condition for avoiding damage to per-
sons and to the product during maintenance and repair works.
Persons performing repair works must familiarize themselves with these regulations.
The proper repair of these Doosan-products requires the employment of suitably trained and skilled staff.
The repairer is obliged to perform the training.
The following safety references are used in the present Repair Manual:
Serves as reference to special working procedures, methods, information,
the use of auxiliaries etc..
This word is used for precautions that must be taken to
avoid actions which could shorten the life of the dump truck.
This word denotes safety messages for hazards which could
result in minor or moderate injury if the hazard is not avoided.
This word might also be used for hazards where the only
result could be damage to the dump truck.
Illustrations, drawings and parts do not always represent the original;
the working procedure is shown. The illustrations, drawings, and
parts are not drawn to scale; conclusions regarding size and weight
must not be drawn (not even within one representation).
The works must be performed according to the description.
REFERENCE: Prior to starting the checks and repair works, thoroughly
study the present instructions.
This word denotes safety messages where there is a high
probability of serious injury or death if the hazard is not avoided.
These safety messages usually describe precautions that
must be taken to avoid the hazard. Failure to avoid this hazard
may result in serious damage to the dump truck.
Is used, if lacking care can lead to personal injury or danger to life.
REFERENCE: After the repair works and the checks, the expert staff must
convince itself that the product is properly functioning again.
Structure of the Repair Manual
DANGER
CAUTION
NOTE
