SHOP MANUAL
DRIVE LINE
Ch 3 page 180 Ch 3 page 181
DRIVE LINE
Safety precautions.
Connect the articulation lock to front frame.
Secure the machine with wheel chocks on the front
wheel.
Drain the oil from axle housing and tandemhousing.
Draining of oil from tandem housing is not neces-
sary if removal takes place just for work on the
tandem bearing.
Disassemble Tandem housing unit
CAUTION
CAUTION
NOTE
Figure 523
Figure 522
Figure 524
