Doosan DA40 - Removal and refitting of LKV axle insert; Separation of LKV axle insert from transmission:

SHOP MANUAL
TRANSMISSION
Ch 2 page 50 Ch 2 page 51
TRANSMISSION
Separation of LKV axle insert from transmis-
sion:
Loosen the hexagon screws.
We recommend to loosen the bolted connection with a
power wrench.
(S) Power wrench
Remove the hexagon screws (1).
Loosen the cylindrical screw and remove the clip (2).
Fit an eyebolt and separate axle insert from transmission us-
ingthe lifting tackle.
(S) Eyebolt
1
2
Removal and refitting of LKV axle insert
Figure 112
Figure 113
Figure 114
Figure 115
