SHOP MANUAL
DRIVE LINE
Ch 3 page 84 Ch 3 page 85
DRIVE LINE
Pull off both bearing inner races (differential bearing).
(S) Quick-acting grip 509254
(S) Quick-acting grip 509255
(S) Basic tool 504243
Dismantle Differential
If necessary, loosen screw connection (Figure 229), resp.
bore off the rivet joint (according to the version), and
separate crown wheel from differential case.
Loosen hex. head screws, remove housing, cover and
disasssemble components.
Figure 229
Figure 228
Figure 227
