SHOP MANUAL
TRANSMISSION
Ch 2 page 12 Ch 2 page 13
TRANSMISSION
100 Hours clutch calibration (AEB)
AEB = Automatic Filling Parameter Adjust-
ment.
To optimise the transmission, run the AEB-
Tester
1. Push MENU on the display screen
2. Select SERVICE
Transmission oil temperature must be above 75 degrees celcius when calibrating.
Transmission clutch calibration must be performed after every oil change in transmission.
Clutch calibration
Start the engine and run it on 800 - 1000 RPM.
Activate parking brake and make sure the vehicle is not moving during
calibration.
Transmission oil temperature must be 75 degrees celsius or above.
Follow instruction on display as shown below.
CAUTION
NOTE
Figure 6
Figure 5
To Next Page
