SHOP MANUAL
Engine
Ch 1 page 116
1. Fit two guide pins 8412 in the crankshaft flange.
2. Fit the flywheel on the crankshaft.
3. Lock the flywheel using tool:
- 512563 for engines with unit injector.
4. Torque tighten the bolts alternately to
130 Nm and then a further 90°.
5. Fit the engine speed sensors.
Fitting the flywheel
Always use new bolts and washer.
NOTE
Figure 223
Figure 224
Figure 225
