SHOP MANUAL
Engine
Ch 1 page 178
Renewing the gasket
Important !
Use only Loctite 406 when fitting the gasket. Loctite 406 does
not contain any solvents that will damage the gasket
Cleanliness when tting the gasket is essential for the
ange to be tight. Keep the surfaces around and on the
ange clean and free from dirt.
1 Remove the gasket from the paper.
2 Fit the gasket on the flange.
3 Apply a thin layer (drops) of Loctite 406.
4 Refit the flange. Use existing bolts with sealing agent or new bolts coated with sealing agent.
NOTE
Figure 353
