Engine
SHOP MANUAL
Ch 1 page 177
15. Fit the gear (26) and the nut (27) as follows:
16. Check the pressure and flow after assembly and fitting. See
Workshop Manual main group 13, Testing the hydraulic system
14. Renew the O-ring 7 on the hexagonal plug. Fit the valve insert
and spring and screw in the plug.
Important!
The shaft end and the gear must be degreased and free of oil and
grease before fitting.
Make sure the control valve is turned as illustrated.
NOTE
Figure 351
Figure 352
