SHOP MANUAL
TRANSMISSION
Ch 2 page 10 Ch 2 page 11
TRANSMISSION
Measuring points and connections
Take measurements when the transmission has reached operating temperature (approx. 80 - 90 °C)
Measuring points for pressure oil and temperatue
53 Clutch - forward V 16+2 bar M12X1.5
54 Clutch - reverse R 16+2 bar M12X1.5
56 Clutch A 16+2 bar M12x1.5
57 Clutch B 16+2 bar M12x1.5
58 Clutch C 16+2 bar M12x1.5
59 Clutch D 16+2 bar M12x1.5
60 Brake F 16+2 bar M12x1.5
61 Clutch E 16+2 bar M14x1.5
62 Lubrication 1.5 bar M14x1.5
64 WK (converter lock-up clutch) 13+1 bar M12x1.5
65 System pressure 16+2 bar M14x1.5
66 Clutch (differential lock) 16+2 bar M12x1.5
10 Breather (transmission) M10x1 12 Nm
11 Breather (LKV axle insert) M10X1 12 Nm
15 Connection towards heat exchanger M48x2 145 Nm
16 Connections from heat exchanger M48x2 145 Nm
28 Connection towards filter M42X2 145 Nm
29 Connection from filter M42x2 145 Nm
30 Connection from filter bypass M42x2 145 Nm
31 Speed sensor n1 turbine M6x12 9.5 Nm
32 Speed sensor n2 primary step M6x12 9.5 Nm
33 Speed sensor n3 secondary step M6x12 9.5 Nm
34 Speed sensor n4 output M6x12 9.5 Nm
70 Temperature sensor Converter/retarder M12x1.5 36 Nm
71 Temperature sensor Oil sump M12X1.5 36 Nm
N° Item designation Connect Nm
