Engine
SHOP MANUAL
Ch 1 page 119
Checking the Drive Belt
Disconnect the cable terminal prior to charging to pre-
vent control unit damage. Avoid boost charging as this
damages the battery over time.
CAUTION
Check the drive belt thoroughly, particularly at the idler rollers.
Check the drive belt for cracks.
The drive belt must be renewed if it has cracks.
NOTE
Check drive belt wear.
The drive belt is starting to become worn, but can be
retted.
NOTE
Figure 229
Figure 230
Figure 231
