Doosan DA40 - WDB cirquit front brake

SHOP MANUAL
DRIVE LINE
Ch 3 page 46 Ch 3 page 47
DRIVE LINE
WDB cirquit front brake
Front brake cirquit
6660
6040
6220
6140
Hub
Rhs
6800
6780
6300
To the
hub Lhs
Front
service
brake
valve
Rear service brake
Brake valve
6660 Oil cooler unit
6040 Oil reservoir
6220 Filter (No Bypass)
6140 Circulation pump
6800 Non return valve
(Open at 1 bar)
6780 Test connector
6300 Temp sensor bloc
k
Hub Rhs
1 bar
Figure 122
