Doosan DA40 - Assemble the tandem housing to the axle; housing.

SHOP MANUAL
Assemble the tandem unit
Screw M20x150 ISO4014-10.9
Apply locking loquid: Loctite 245
Torque limit: 560 Nm.
Be aware of personal injury.
Assemble the tandem housing to the axle
housing.
WARNING
DRIVE LINE
Ch 3 page 186 Ch 3 page 187
DRIVE LINE
After attraction, test the movement with to lift the end of
Tandem housing.
500 -
1000 Nm
Fill oil on the axle housing.
Oil: Spirax S3 ALS 80W-90. (For fluid type and specifications, refer
to the DOOSAN Operating & Maintenance Manual Chapter 6)
Fill up the machine with oil when it is placed on a straight level
Check the level of oil in the Tandem housing
Be aware of personal injury.
WARNING
Figure 539
Figure 540
Figure 542
Figure 541
