Ch 6 page 49
ELECTRICAL SYSTEM
SHOP MANUAL
To be implented
Alarmbits 4: .space 2 ; ** General hydraulic 1 **
Sensor error on A(TIP)
TIP-UP proportional solenoid abnormal value
TIP-UP proportional solenoid open circuit
TIP-DOWN proportional solenoid abnormal value
TIP-DOWN proportional solenoid open circuit
FLOAT solenoid short circuit
FLOAT solenoid open circuit
Hydraulic tank level sensor error
Hydraulic tank level too low
Hydraulic tank level low
Alarmbits 5: .space 2 ; ** General hydraulic 2 **
Sensor error on PBOUT
PBOUT pressure too low
PBOUT pressure too high
PARK-BRAKE solenoid short circuit
PARK-BRAKE solenoid open circuit
FAN proportional solenoid abnormal value
FAN proportional solenoid open circuit
FAN-STOP solenoid short circuit
FAN-STOP solenoid open circuit
Alarmbits 6: .space 2 ; ** General hydraulic 3 **
Sensor error on PUMP1
PUMP1 pressure too low
PUMP1 pressure too high
Sensor error on PUMP2 (*3)
PUMP2 pressure too low (*3)
PUMP2 pressure too high (*3)
Sensor error on HYDRAULIC-TANK
Too high temperature in HYDRAULIC-TANK
REAR-DIFF solenoid short circuit (*4)
REAR-DIFF solenoid open circuit (*4)
EB proportional solenoid abnormal value
EB proportional solenoid open circuit
High temperature warning in HYDRAULIC-TANK
Alarmbits 7: .space 2 ; ** Sensor 1 **
SIFU1 supply short circuit
Fuel tank level sensor error
Alarm (red,
loud alarm)
Warning (amber,
short beep)
Alarm (red,
loud alarm)
Warning (amber,
short beep)
Alarm (red,
loud alarm)
Alarm (red,
loud alarm)
