FRONT WAGON

Ch 7 Page 2 Ch 7 Page 3

FRONT WAGON

The Front Wagon is built up around the front frame, which is the base for the engine and the trans-

mission. The frame is resting on the front suspension, and connected to the rear wagon in the

articulation bearing.

The fenders and mudguards are attached to the frame as well as the cab and the bonnet.

Both the cab and the bonnet are hinged for easy access to engine and transmission for inspection

and maintenance.

7.1 Introduction

Front Suspension

Articulation

Bearing

Cab

Fender

Mudguard

Bonnet

Figure 1
