SHOP MANUAL
DRIVE LINE
Ch 3 page 60 Ch 3 page 61
DRIVE LINE
The service brake consist of:
Hydraulic pump, Accumulators, Accumulator valve, Brake pedal, Control valve, and calippers.
See the Shop Manual: Chapter 5
Service brake description
Pedal brake valve
Accumulators
Left
hand
side
Right
hand
side
Front wagon
Rear wagon
Rear wagon
Parking brake
Accumulator Valve
Hydraulic pump
Figure 163
Figure 167
Figure 164
Figure 165
