Doosan DA40 - 8.1 Introduction

SHOP MANUALSHOP MANUAL
REAR WAGON
Ch 8 Page 2
Ch 8 Page 3
REAR WAGON
Dumper
Body
Tilt Bearing
Rear
Frame
Optional Tail
Gate
Tilt Cylinders
Wheels,
Axles and
Drive Shafts
Tail gate
Operating
Chain
8.1 Introduction
The main component of the rear wagon is the rear frame, which is the base for the dumper body and the sup-
port for the rear axles.
The rear wagon is connected to the front wagon in the articulation bearing.
The tiltable dumper body is attached to the rear frame in the tilt bearing.
For work on the rear wagon drive line, ref. chapter 3
Figure 1
