SHOP MANUAL
Engine
Ch 1 page 142
1.Place the bearing shells in the main bearing seats in the cylinder
block and in the main bearing caps. Then lubricate the bearing
surfaces with engine oil.
2. Lift in the crankshaft.
The outside of the bearing shells must not be lubricated.
3. Lubricate the bolt thread and the surface of the main bearing
cap where the bolt is tightened, see illustration. Scania engine oil
can be used.
4. Insert the main bearings in the crankshaft
bearing caps and fit them.
Main bearing cap: 110Nm + 90°
The bolts can only be reused three times. Check the number of
punch marks on the head, if a screw has three punch marks it
must be replaced.
Fitting
Fit the main bearings and caps in the same place as before
removal.
NOTE
Figure 281
Figure 282
NOTE
CAUTION
Figure 283
