Doosan DA40 - Replacement of camshaft bearing

To Next Page

To Previous Page

Engine

SHOP MANUAL

Ch 1 page 131

Replacement of camshaft bearing

8467

Work description

1. Remove the camshaft according to the

section Camshaft, removal.

2. Remove the camshaft cover at the front end

of the engine.

Wipe around the edges and the bearing seat surfaces around the

old bearings to avoid damaging the contact surfaces when tting

the new bearings.

3. Wipe the bearing seat surfaces clean around

the old bearings.

The recess in the bearing joint must be turned towards the front

of the engine.

4. Place the new bearings in the space

between the bearing seats for the camshaft.

5. Place the ﬂange nuts on the threaded stem,

included in tool 8467, as illustrated.

1. Threaded stem with eight ﬂange nuts

2. Press drift

3. Flange

NOTE

Figure 256

Figure 257

Figure 258
